SL500 Micro Shearlock (Maglock)

The SL500 Micro Shear Lock is a high-security electromagnetic locking solution designed for use with access control systems, door entry systems, intercom systems, and electronic security installations. Suitable for commercial, industrial, educational, healthcare, residential, and public sector environments, it provides exceptional holding force whilst maintaining a compact and discreet installation profile.

A shear lock combines the holding strength of an electromagnetic lock with a mechanical shear locking mechanism that provides enhanced resistance to forced entry. When the door closes, the armature aligns with the lock body and is secured through both magnetic attraction and mechanical shear resistance, delivering significantly higher holding force than many conventional magnetic locks.

Operating from 12VDC or 24VDC, the SL500 provides an impressive holding force of up to 2,600lbs (1,200kg) in shear. The lock features an adjustable locking delay from 0.5 to 25 seconds, allowing sufficient time for the armature plate to align correctly before the shear mechanism fully engages. It also incorporates COM, NO and NC monitoring contacts for integration with compatible access control and monitoring systems.

Available Model

• SL500 – Micro Shear Lock

Key Features

• Micro Shear Lock
• Holding Force up to 2,600lbs (1,200kg) in Shear
• 12VDC or 24VDC Operation
• Fail Safe Operation
• Adjustable Locking Delay from 0.5 to 25 Seconds
• COM / NO / NC Monitoring Contacts
• Compact Installation Profile
• High-Security Locking Solution
• Suitable for Access Control Systems
• Suitable for New Installations and Retrofit Projects
• Reliable Electromagnetic and Mechanical Shear Locking

Typical Applications

• Access Control Doors
• Commercial Buildings
• Office Entrances
• Healthcare Facilities
• Educational Facilities
• Government Buildings
• Restricted Access Areas
• High-Security Doors
• Internal Security Doors
• Industrial Premises

Compatibility and Accessories

The SL500 Micro Shear Lock is designed to integrate with a wide range of access control and electronic security equipment.

This shear lock is commonly used with access control systems, door entry intercoms, keypads, proximity readers, press to exit buttons, timers, relays and power supplies.

When building a complete system, please check the operating voltage, door type, mounting requirements, alignment requirements and any emergency release requirements before ordering.

• Access Control Systems
• Electric Locks
• Magnetic Locks (Maglocks)
• Door Entry Systems
• Intercom Systems
• Keypad Entry Systems
• Proximity Readers
• Press to Exit Buttons
• Relays and Timers
• Door Monitoring Systems
• Emergency Door Release Units

Technical Specification

• Product Type: Micro Shear Lock
• Operation: Fail Safe
• Operating Voltage: 12VDC or 24VDC
• Holding Force: Up to 2,600lbs (1,200kg) in Shear
• Locking Delay: Adjustable 0.5 to 25 Seconds
• Monitoring Contacts: COM / NO / NC
• Dimensions: 182mm × 30mm × 25mm (H × W × D)

SL500 Product Information

The SL500 Micro Shear Lock provides a powerful and discreet locking solution for access control installations requiring exceptional security. Featuring up to 2,600lbs (1,200kg) holding force in shear, an adjustable locking delay and monitoring contacts, it is well suited to commercial, industrial and high-security applications where a compact electromagnetic shear lock is required.

Frequently Asked Questions

What is a micro shear lock?

A micro shear lock combines electromagnetic holding force with a mechanical shear locking action, providing enhanced resistance to forced entry whilst maintaining a compact installation profile.

What holding force does the SL500 provide?

The SL500 provides up to 2,600lbs (1,200kg) of holding force in shear.

Why does the SL500 have an adjustable locking delay?

The adjustable locking delay allows the door and armature plate sufficient time to align correctly before the lock fully engages, helping ensure reliable and consistent operation.

Is the SL500 fail safe?

Yes. The SL500 operates as a fail-safe shear lock, meaning it releases automatically when power is removed.

What are the COM, NO and NC contacts used for?

The COM, NO and NC monitoring contacts provide status feedback for compatible access control and monitoring systems.

What voltage does the SL500 operate on?

The SL500 operates from 12VDC or 24VDC power supplies.

Can the SL500 be used with access control systems?

Yes. The SL500 is compatible with access control systems, door entry systems, intercoms, keypads, card readers, emergency release devices and other electronic security equipment.

Is there a fire-rated version available?

Yes. A dedicated FR-SL500 Fire Rated Micro Shear Lock is available for applications requiring tested fire-door suitability and associated fire certification.
