FR-U10002 / FR-U10002DSU Fire Rated Monitored Mini Magnetic Lock (Maglock)

The FR-U10002 and FR-U10002DSU Fire Rated Monitored Mini Magnetic Locks are high-performance electromagnetic locking solutions designed for use with fire-rated doors, access control systems, emergency exit systems, and door entry installations. Suitable for commercial, industrial, educational, healthcare, residential, and public sector environments, they provide secure door locking whilst maintaining compliance with fire safety requirements.

An electromagnetic lock, magnetic lock, or maglock consists of an electromagnet mounted to the door frame and a matching armature plate mounted to the door. When power is applied, the electromagnet generates a magnetic field that securely bonds the armature plate to the lock body, creating a strong locking force. When power is removed, the magnetic bond releases immediately, allowing safe and unrestricted egress.

Manufactured from durable aluminium and designed specifically for fire-rated applications, the FR-U10002 range has been tested to BS EN 1634-1 and is suitable for installation on FD30 and FD60 fire doors. Both models include lock status monitoring with an output for connection to compatible access control systems. Each lock also features LED lock status indication, showing green when unlocked and red when locked. The FR-U10002DSU version additionally includes a door status output.

Available Models

• FR-U10002 – Fire Rated Monitored Mini Magnetic Lock
• FR-U10002DSU – Fire Rated Monitored Mini Magnetic Lock with Door Status Output

Key Features

• Fire-rated mini magnetic lock
• Holding force up to 600lbs (272kg)
• Operating voltage 12~24VDC (selectable)
• Aluminium housing
• Fail-safe operation
• Fire tested to BS EN 1634-1
• Suitable for FD30 and FD60 fire doors
• Monitored Lock Output
• Door Status Output on FR-U10002DSU only
• LED Lock Status Indication
• Suitable for access control systems
• Compact design
• Reliable locking performance
• Suitable for internal installations

Typical Applications

• Fire-rated doors
• Access control systems
• Emergency exit systems
• Commercial buildings
• Office buildings
• Schools and universities
• Healthcare facilities
• Apartment buildings
• Public buildings
• Secure internal doors

Compatibility

The FR-U10002 Series Mini Magnetic Locks are designed to integrate with a wide range of access control and door security equipment, making them suitable for both new installations and retrofit projects.

• Access control systems
• Emergency door systems
• Fire alarm systems
• Door entry systems
• Emergency exit systems
• Keypad systems
• Proximity readers
• Building management systems
• Power supplies


Technical Specification

• Product Type: Fire Rated Monitored Mini Magnetic Lock
• Operating Voltage: 12~24VDC (Selectable)
• Holding Force: Up to 600lbs (272kg)
• Housing Material: Aluminium
• Operation: Fail-Safe
• Lock Monitoring: Monitored (All Models)
• Door Status Output: FR-U10002DSU Only
• LED Indication: Lock Status LED - Green Unlocked / Red Locked

• Fire Rating: BS EN 1634-1 Tested
• Door Compatibility: FD30 & FD60 Fire Doors
• Dimensions: 42mm x 250mm x 26mm (H x W x D)

FR-U10002 / FR-U10002DSU Product Information

The FR-U10002 and FR-U10002DSU Fire Rated Monitored Mini Magnetic Locks provide a reliable and compliant locking solution for fire-rated door applications. Featuring up to 600lbs holding force, fail-safe operation, BS EN1634-1 fire testing, and compatibility with FD30 and FD60 fire doors, they are ideal for access control and emergency exit installations requiring secure locking and fire door compliance.

Frequently Asked Questions

What is the FR-U10002 used for?

The FR-U10002 is a fire-rated magnetic lock used to secure fire doors within access control, emergency exit, and door entry systems.

What is the difference between the FR-U10002 and FR-U10002DSU?

The FR-U10002 and FR-U10002DSU are both monitored fire rated mini magnetic locks with LED lock status indication. The FR-U10002DSU additionally includes a door status output for connection to compatible access control systems.

Is the lock suitable for fire doors?

Yes. Both models have been tested to BS EN 1634-1 and are suitable for installation on FD30 and FD60 fire-rated doors.

What holding force does the lock provide?

The lock provides a holding force of up to 600lbs (272kg).

Is the lock fail-safe?

Yes. The FR-U10002 range operates as a fail-safe lock, meaning the door unlocks automatically when power is removed.

What voltage does the lock operate on?

The lock supports selectable 12VDC or 24VDC operation.

Can the lock be used with access control systems?

Yes. The FR-U10002 range is fully compatible with access control systems, door entry systems, fire alarm interfaces, and emergency exit equipment.

Is the lock suitable for commercial buildings?

Yes. It is suitable for commercial, educational, healthcare, industrial, residential, and public sector environments requiring fire-rated door security.
